Features
- 12 gauge steel moldboard
- Brake formed for added strength
- Compression trip moldboard design with rubber impact stops across the lower position of the moldboard
- Adjustable moldboard attack angle
- 1/4” thick moldboard ribs. Double ribs at drive points
- 1/2” thick base angle
- 27” nominal height tapering from the center line of plow to 37” of discharge height
- AASHO standard cutting edge
- 1” diameter pin holes on 30-1/2” centers
- Reversible pushframe up 32 degrees to either side of bulldoze position
- Twin 3” bore by 12” double acting reverse cylinders
- Approximate weight: 1,205 lbs.
